As Wi-Fi 7 garners widespread interest for its blazing speeds and cutting-edge capabilities, another wireless innovation, Wi-Fi HaLow, is quietly carving a niche in the ever increasing and demanding applications of IoT.
This is because unlike the more broadly known Wi-Fi standards, which focus on maximising data transmission rates and reducing latency for consumer devices, Wi-Fi HaLow is poised to address the unique needs of IoT applications – like extending the reach of wireless connectivity to areas previously considered beyond the scope of conventional Wi-Fi. Therefore, its application in the IoT connectivity landscape is well suited, especially as the number of smart devices in homes, industries, and cities – things that rely heavily on Wi-Fi or LoRaWAN – continues to explode.
What is Wi-Fi HaLow?
Traditional Wi-Fi technologies, while adequate for high-bandwidth applications like video streaming and online gaming, fall short in scenarios where devices need to communicate over longer distances or through challenging physical barriers. Wi-Fi HaLow steps into this gap, offering a solution that balances the need for range and power efficiency with the reliability and security expected from Wi-Fi networks.
The Wi-Fi HaLow wireless standard represents a wireless technology specification grounded in the IEEE 802.11ah protocol, unveiled in 2016. It operates on sub-1GHz frequencies, diverging from the traditional Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E, and Wi-Fi 7 protocols, which utilise 2.4GHz, 5GHz, and 6GHz frequencies.
Offering connectivity up to a kilometre, and even further with a line-of-sight connection, Wi-Fi HaLow benefits from lower frequencies’ capacity to travel longer distances. However, this also entails narrower channels and a reduced bandwidth, yielding slower data rates. Nonetheless, it can achieve data speeds from 150Kbps over extended distances to 86.7Mbps over shorter spans.
Designed not as a replacement but to complement existing Wi-Fi protocols, Wi-Fi HaLow facilitates connectivity over longer distances without the need for wireless extenders, multiple access points, or intricate wired setups. It finds its best application in IoT devices, smart city endeavours, and mesh networking.
In the US, Wi-Fi HaLow utilises the 900MHz frequency within the licence-exempt spectrum, available for free use. Its operational frequencies may vary in other countries, depending on the availability of sub-gigahertz bands.
How Wi-Fi HaLow differs from traditional Wi-Fi
Wi-Fi HaLow’s ability to function on sub-1GHz frequencies is a game-changer for wireless connectivity. This lower frequency band allows Wi-Fi HaLow to offer superior wall penetration and signal range compared to the 2.4GHz and 5GHz bands used by traditional Wi-Fi standards. This characteristic is particularly advantageous in environments with numerous physical obstructions or in outdoor settings where direct line-of-sight may not always be possible.
This feature is something shared by LoRaWAN, which has high signal penetration through obstacles, a trait vital for connectivity in challenging environments. However, their key differences lie in range, data rate, and application focus. Wi-Fi HaLow, operating in the sub-1GHz spectrum, strikes a balance between range and data throughput, making it ideal for IoT applications needing relatively higher data speeds, like video security systems and smart home devices. Conversely, LoRaWAN, designed for very long-range communication and minimal power consumption, suits applications requiring minimal data transmission over extensive distances, such as environmental sensors and smart meters.
Moreover, the reduced frequency enhances device connectivity in densely built areas, where traditional Wi-Fi signals may weaken or become unreliable due to interference from walls and other structures.
Additionally, Wi-Fi HaLow’s design includes features specifically tailored for IoT applications, such as a highly efficient power-saving protocol. This protocol enables devices to remain dormant with minimal energy consumption and wake up only when communication is necessary. This capability not only extends the battery life of devices but also allows for the deployment of IoT solutions in locations where power sources are limited or non-existent.
The ability to support over 8,000 devices simultaneously on a single Wi-Fi HaLow network addresses the scalability challenge faced by many IoT applications, making it an ideal choice for large-scale deployments.
Wi-Fi HaLow vs. other wireless technologies
When comparing Wi-Fi HaLow to technologies like Z-Wave, Zigbee, and Thread, its technical superiority becomes evident in certain aspects. For example, Wi-Fi HaLow’s operation in the sub-1GHz spectrum offers a balance between range and power efficiency that is hard to match. Unlike Z-Wave and Zigbee, which also operate in sub-1GHz frequencies, Wi-Fi HaLow provides significantly higher data rates, making it suitable for a wider range of applications, from simple sensor data collection to more bandwidth-intensive tasks like video surveillance.
Moreover, Wi-Fi HaLow’s security features are built on the robust WPA3 protocol, offering a level of security that is currently considered state-of-the-art for wireless communication. This contrasts with Zigbee’s security, which has faced scrutiny over potential vulnerabilities. Additionally, Wi-Fi HaLow’s capacity to seamlessly integrate into existing Wi-Fi networks without requiring additional hubs or controllers simplifies deployment and management, addressing a common challenge with technologies like Zigbee and Thread, which often require a dedicated hub or coordinator.
The benefits of Wi-Fi HaLow
The operational benefits of Wi-Fi HaLow, due to it operating on a separate frequency from traditional Wi-Fi, means it avoids the overcrowded 2.4GHz and 5GHz bands, significantly reducing the likelihood of interference. This unique capability ensures more reliable connections for IoT devices, which are often critical to the operations of smart homes, industrial environments, and smart cities. Moreover, Wi-Fi HaLow’s ability to provide connectivity over vast areas from a single access point simplifies network infrastructure, reducing the need for extensive wiring and multiple network extenders.
In practical terms, Wi-Fi HaLow enables the deployment of IoT devices in scenarios previously considered challenging or impractical. For instance, agricultural IoT applications can benefit from Wi-Fi HaLow’s extended range and low power consumption, allowing for real-time monitoring and data collection over large areas with minimal infrastructure. Similarly, in urban environments, Wi-Fi HaLow can facilitate the deployment of smart city technologies, such as street lighting and traffic monitoring systems, without the complexity and expense of traditional network setups.
The ecosystem for Wi-Fi HaLow is gradually expanding, with an increasing number of manufacturers recognising its potential and investing in compatible devices. The initial slow adoption rate is typical for new technologies, as both infrastructure and device support need to develop simultaneously. However, the growing interest in IoT applications and the need for more efficient, reliable connectivity solutions are driving Wi-Fi HaLow forward.
Manufacturers are exploring innovative uses for Wi-Fi HaLow beyond traditional networking equipment. For example, the integration of Wi-Fi HaLow into security cameras represents a significant advancement, allowing for more flexible placement and longer battery life.
Wi-Fi HaLow is therefore uniquely positioned to offer layers of connectivity that separates it from the other types that the IoT ecosphere relies on. Where it be due to its extended range, low power consumption, and high device capacity positions, Wi-Fi HaLow is positioned as an attractive choice for the next generation of smart devices and systems, and even aid the accelerating rollout of smart cities.
